SE-600-5 5V 100A 500w high switch power supply
SE-600 series single output power supply
AC DC SWITCHING POWER SUPPLY
* AC input active surge current limiting
* AC input range selected by switch
* Protections:Short circuit / Overload / Over voltage / Over temperature
* Forced air cooling by built-in DC fan
* High power density 4.9w/inch3
* Built-in remote sense function
* UL approved
* Low cost
* 2 years warranty
| MODEL | SE-600-5 | SE-600-12 | SE-600-24 | SE-600-48 |
| DC output voltage, current | 5V 0 ~ 100A | 12V 0 ~ 50A | 24V 0 ~ 25A | 48V 0 ~ 12.5A |
| Wave and noise | 150mVp-P | 150mVp-P | 150mVp-P | 180mVp-P |
| Inlet wire stability | ±0.5% | ±0.5% | ±0.5% | ±0.5% |
| Load stability | ±1% | ±0.5% | ±0.5% | ±0.5% |
| Efficiency | 78% | 83% | 87% | 88% |
| Adjustable range for DC voltage | ±10% | ±10% | ±10% | ±10% |
| Input voltage range | 90~132VAC/180~ 264VAC by switch 254~ 370VDC 47-63Hz | |||
| lmpact current | lmpact current 30A/115VAC 50A/230VAC | |||
| Overlcad protection | 105% ~150% cut off the output, automatic recovery | |||
| Over voltage protection | 120%~ 140% shut down O/P voltage, re- power on to recover | |||
| Setup, rise, hold up time | 1000ms, 50ms, 1 6ms/230VAC | |||
| Withstand voltage | I/P-O/P: 1 5kV I/P- FG:1 5kV O/P- -FG: O.5kV 1minute | |||
| Isolation resistance | |/P-O/P I/P-FG O/P-FG: 500VDC/100MO | |||
| Working temperature | -10℃~ +50℃ | |||
