JXQ-2E-D6-19PF-G05BL-1M Absolute Rotary Encoder
| Output form |
Supply voltage DC(V) |
Current consumption (mA) |
Output voltage | Rise time (ns) |
Descent time (ns) |
Transmission rate | ||
| VH | VL | SSI | BiSS | |||||
| RS422 | 5±0.25 | ≤120 | ≥2.5 | ≤0.5 | ≤200 | ≤200 | 0.032~4 | 0.065~10 |
Wiring diagram
| THREAD COLOR | RED | BLACK | BLUE | BLUE/ BLACK |
GREEN | GREEN/ BLACK |
BLOCK | |
| SIGNAL | 5V | GND | MA | NMA | SLO | NSLO | SHELL |
Environmental parameter
| Relative humidity |
Operating temperature(℃) |
Storage temperature(℃) |
Impact resistance(m/s²) |
Vibration resistance(m/s²) |
Grade of protection |
| RH85%condensation is unacceptable |
-20~85 | -30~90 | 980(x,y,z three times each direction, each time 6ms) |
98(10~2000Hz, x,y,z each 2h) |
IP54 |
